Temperature Sensor

• A built-in sensor monitors oven temperature and adjusts the cooking elements to help food bake evenly.

Hidden Bake Element

• Simplifies cleanup with the bake element hidden beneath the oven floor, leaving a smooth interior surface that is easy to wipe clean.

True convection cooking

• Cook food faster with a rear fan and third heating element to circulate hot air over, under, and around food.

Rapid Preheat

• The Rapid Preheat option preheats the oven 25% faster and saves time and energy. Using all of the range elements and a fan, the oven heats up more quickly and creates the ideal temperature for single rack baking. Now cutting preheat time for your next batch of chocolate chip cookies or apple crisps is easy.

FIT system

• Whirlpool® wall ovens come with the parts to fit, right out of the box, guaranteed. If your new wall oven doesn’t fit, Whirlpool brand will pay up to $250 toward cabinet modification.

SteamClean option

• Clean up after every day light spills using only heat and 1-1/4 cups of water—no harsh chemicals or cleaners needed. Used periodically to clean light spills on the bottom of the oven, it keeps the oven clean and reduces the need for frequent self-clean cycles.

Largest capacity wall oven available

• Cook multiple dishes for a large family meal or prepare treats for a bake sale with Whirlpool® wall ovens with up to 8.6 cu. ft. capacity. Models with the largest capacity wall oven available* offer enough room to handle even your largest cooking tasks.

Convection Conversion

• Your oven will do the math for you when you need to convert traditional recipes for convection cooking, automatically adjusting cooking times and temperatures.

Extra-Large Oven Window

• Monitor cooking progress without opening the door with the new EasyView™ extra-large oven window. The extra-large design adds a sleek, modern accent to the kitchen, saves energy and keeps oven temperatures steady and undisturbed.

Precise Clean® cleaning system

• The Precise Clean™ cleaning system tracks the time between self-clean cycles to determine the right cycle time. This makes sure the self-cleaning cycle only lasts as long as necessary for optimal cleaning and energy savings. No harsh chemicals or cleansers are required.

ADA Compliant

ADA Compliant : No

Amps

Amps : 40

Bake Element Power

Bake Element Power : 2800W Both

Broiler Element Power

Broiler Element Power : 3600W Both

Broiler Location

Broiler Location : Top Center Both

Control Type

Control Type : Electronic Touch

Convection Element Power

Convection Element Power : 2500

Convection Element Type

Convection Element Type : True

Convection Functions

Convection Functions : Bake Broil Roast Upper,Convection Conversion Upper

Dimensions

Carton Depth : 30 1/2 inch

Carton Height : 52 7/8 inch

Carton Width : 34 1/2 inch

Cutout Depth (in) : 24 inch

Cutout Height (in) : 50 1/4 inch

Cutout Width (in) : 28 1/2 inch

Depth : 26 7/16 inch

Height : 51 1/2 inch

Width : 30 inch

Depth Closed Excluding Handles : 24 1/2 inch

Depth With Door Open 90 Degree : 46 3/4 inch

Gross Weight : 266 inch

Net Weight : 0.0 inch

Dimensions|Capacity(FT3,cubic feet)

Dimensions|Capacity(FT3,cubic feet) : 10.00

Dimensions|Cutout Depth(IN,inches)

Dimensions|Cutout Depth(IN,inches) : 24

Dimensions|Cutout Height(IN,inches)

Dimensions|Cutout Height(IN,inches) : 50 1/4

Dimensions|Cutout Width(IN,inches)

Dimensions|Cutout Width(IN,inches) : 28 1/2

Display Color

Display Color : Blue/Red

Display Type

Display Type : Digital

Door Broil Position

Door Broil Position : Closed

Door Removable

Door Removable : Yes

Door Type

Door Type : Glass Window

Fuel Type

Fuel Type : Electric

Handle Color

Handle Color : Stainless Steel

Handle Material

Handle Material : Metal

Hidden Bake

Hidden Bake : Yes

Hz

Hz : 60

Interior Coating

Interior Coating : Porcelain

Interior Color

Interior Color : Grey

Light Type

Light Type : Incandescent

Lower Oven Capacity (Cu Ft.)

Lower Oven Capacity (Cu Ft.) : 5.0

Lower Oven Number of Oven Lights

Lower Oven Number of Oven Lights : 2

Number of Bake Elements

Number of Bake Elements : 1

Number of Lower Oven Racks

Number of Lower Oven Racks : 2

Number of Lower Rack Guides

Number of Lower Rack Guides : 6

Number of Upper Oven Racks

Number of Upper Oven Racks : 3

Number of Upper Rack Guides

Number of Upper Rack Guides : 6

Oven Cooking System

Oven Cooking System : Convection Upper/Thermal Lower

Oven Rack 1 Type

Oven Rack 1 Type : Standard

Oven Self-Cleaning

Oven Self-Cleaning : Steam Clean

Oven Type

Oven Type : Double

Oven Window Size

Oven Window Size : Extra Large Upper and Lower Oven

Power On Indicator Light

Power On Indicator Light : Yes

Rack Guide Type

Rack Guide Type : Molded

Selections

Selections : Keep Warm Setting,Audible Signal,Control Lock,Cancel/Off,Automatic Door Latch,Cook Time Indicator,Delay Start,Warm Hold,Sabbath Mode,Rapid Preheat,Clock,Timer

Size (in.)

Size (in.) : 30

UL

UL : UL

Upper Oven Capacity (Cu Ft.)

Upper Oven Capacity (Cu Ft.) : 5.0

Upper Oven Interior Depth (in.)

Upper Oven Interior Depth (in.) : 19

Upper Oven Interior Height (in.)

Upper Oven Interior Height (in.) : 18

Upper Oven Interior Width (in.)

Upper Oven Interior Width (in.) : 25

Upper Oven Number of Oven Lights

Upper Oven Number of Oven Lights : 2

Volts

Volts : 240

• Dimension Guide

• Energy Guide

• Installation Instruction

• Use and Care
