Patented Star Burners

• Our exclusive, sealed 3-in-1 Star Burner's unique five-point design offers a reduced cold spot, faster time to boil and the ExtraLow feature. The coverage area allows for more ports and more flame distribution than a round burner. THERMADOR EXCLUSIVE

ExtraLow

• The ExtraLow feature provides the widest variety of temperature control of any simmer system. It cycles on and off to maintain temperatures as low as 100 degree . Perfect for simmering delicate sauces or keeping food warm without scorching. THERMADOR EXCLUSIVE

Fastest Time to Boil

• The unique five-point design of our patented Star Burners directs heat evenly from the center of the pan to its edges for faster time to boil. It boils water over 50% faster than leading competitors.

QuickClean Base

• The raised pedestal burner and porcelain maintop have been crafted for perfect integration and easy cleanup. A hand and sponge fit easily under each burner to wipe the surface clean and a teardrop emboss reduces food buildup near the base. THERMADOR EXCLUSIVE

INNOVATION

• Exclusive, patented Star Burner - most even heating, unsurpassed flame coverage

• Precision simmering capabilities as low as 100 degree F (375 BTU) with 2 ExtraLow Simmer burners

• QuickClean Base designed for easy surface cleaning

PERFORMANCE

• Professional style, continuous cast iron grates

• Continuous porcelain, easy to clean cooking surface

• Every burner 18,000 BTU (NG)

• Widest range of simmer options from 375 BTU to 3,000 BTU

• Star design delivers superior heat spread for any size pan

• Simmer without stirring/scorching with exclusive ExtraLow

• Powerful, 27,000 BTU bake and 20,000 BTU broil burners

• Convection Bake offers precise multi-level baking results

• Massive oven capacity of 5 cu.ft.

• Six rack levels for multiple item cooking

• Full Access telescopic racks, integrated easy-grip handle

• Electronic oven control ensures precise heating

• Large oven door window for maximum viewing

• Powerful halogen lighting illuminates the oven cavity

• Sabbath mode

DESIGN

• Bold Professional design

• Truly Flush Mounted, 24" standard cabinet depth

• Patented Pedestal Star Burner with QuickClean Base

• Restaurant style metal knobs

• Signature blue indicator lighting

• 36" units ship standard with island trim included

Product Features

Product Features : PRODUCT FEATURES

Product Features : Temperature control electronic

Product Features : Time control No

Product Features : Location of 1st heating element front left

Product Features : Type of grate Cast iron

Product Features : Number of double grates 3

Product Features : Knob material Full metal

Product Features : Included accessories 1 x island trim, 1 x Broiler pan

Product Features : Power of 1st heating element (W) 5.27

Product Features : Location of 2nd heating element center left

Product Features : Location of 3rd heating element back left

Product Features : Power of 3rd burner (BTU) 18000

Product Features : Location of 4th heating element middle back

Product Features : Location of 5th heating element back right

Product Features : Power of 5th burner (BTU) 18000

Product Features : Location of 6th heating element center right

Technical Specifications

Technical Specifications : Amps (A) 15

Technical Specifications : Frequency (Hz) 60

Technical Specifications : Gas type Natural gas 15 mbar (USA)

Technical Specifications : Approval certificates CSA

Technical Specifications : Plug type 120V-3 prong

Technical Specifications : Net weight (lbs) 406

Technical Specifications : Gross weight (lbs) 419

Technical Specifications : Adjustable height (in) 7/8

WARRANTY

WARRANTY : Limited warranty, entire appliance, parts and labor (2 years) Two-year warranty is only valid on products purchased after 1/1/2012

• CAD File - DGN format

• CAD File - DWG format

• CAD File - DXF format

• CAD File - ArchiCAD format

• CAD File - IFC format

• CAD File - SKP format

• CAD File - VWX format

• CAD File - Revit format

• Design Guide

• Product Specs
