Slim counter height dimensions

• Just 22 inches wide for easy placement in any small location

Manual defrost

• No temperature fluctuations with a manual defrost system that keeps the cold inside

Open shelves

• Fixed shelves accommodate large items

Door shelves

• Three racks for added storage options

Adjustable thermostat

• Manage the interior temperature with ease and accuracy

Fully finished white cabinet

• Allows the unit to be used freestanding

100% CFC free

• Environmentally friendly design without ozone-damaging chemicals

Exterior

DL2 Temperature Logger USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout : CAS6 6" casters 6" high NSF listed casters

TT Thermometer ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order : PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices

DT Digital Thermostat Install a digital thermostat with external readout for precise temperature management : CAS3 3" casters 3" high NSF listed casters designed for institutional use, made from non-marring hard rubber in gray finish

Alarm Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations : Latch Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.

HUM Humidity Sensor Humidity sensor with min/max readout : HG Cord Add a hospital grade cord equipped with green dot plug with the HG suffix

DL1 Temperature Logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac : L-Installed Lock Add a single key lock to the door with the L option

KEYPAD Battery-powered keypad lock installed for keyless security : AC Keypad Keypad lock powered by appliance power cord for keyless security

Freezer

Door Swing : RHD

Reversible : No

Interior Height : 29.5" (75 cm)

Interior Width : 18.63" (47 cm)

Interior Depth : 19.0" (48 cm)

Shelf Type : Wire

Shelf Qty : 2

Full Door Shelves : 3

Thermostat Type : Dial

Refrigerant Type : R134a

Refrigerant Amount : 2.5 oz.

High Side PSI : 235.0

Low Side PSI : 130.0

Compressor Step Height : 7.5" (19 cm)

Compressor Step Width : 18.63" (47 cm)

Compressor Step Depth : 4.0" (10 cm)

Overview

Height of Cabinet : 33.13" (84 cm)

Height to Hinge Cap : 33.63" (85 cm)

Width : 21.38" (54 cm)

Depth : 25.75" (65 cm)

Depth with door at 90° : 44.5" (113 cm)

Capacity : 5.0 cu.ft. (142 L)

Defrost Type : Manual

Door : White

Cabinet : White

US Electrical Safety : UL

Canadian Electrical Safety : ULC

Energy Usage/Year : 301.0kWh/year

Amps : 1.1

Weight : 90.0 lbs. (41 kg)

Shipping Weight : 95.0 lbs. (43 kg)

Parts & Labor Warranty : 1 Year

Compressor Warranty : 5 Years
