Built-in capable

• Front-breathing design allows fully integrated installation

Stainless steel doors

• Professional look in high quality stainless steel, with a unique curve to add a modern touch to any kitchen

Bottom freezer

• Convenient design keeps all refrigerated storage at eye level for easier use

Digital thermostats

• Separate digital controls let you adjust the refrigerator and freezer section, with a digital display for added convenience

Adaptive intelligent technology

• Innovative sensor technology allows the unit to adjust to your habits, reading your patterns to manage the temperature based on the frequency of door openings and grocery loading

Icemaker

• Factory installed icemaker ensures a steady supply of ice, eliminating the need to maintain cumbersome ice trays

Adjustable glass shelves

• Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up

Adjustable door storage

• Three door racks can be adjusted in height to accommodate a variety of sizes

Wine shelf

• Store bottles safely on an adjustable scalloped steel rack

Humidity controlled crisper

• Large crisper drawer allows you to ensure the optimum storage of fruits and vegetables

ZeroZone deli drawer

• Slide-out drawer allows you to store meats and other deli items at a slightly colder temperature for long-lasting freshness

Multibox storage container

• Removable container with a silicone lid and air-tight seal offers a convenient way to store smaller food items with a strong odor, such as blue-vein cheeses or onions

Removable transparent freezer drawers

• Unique freezer design keeps the cold inside, even when the door is opened

Interior LED refrigerator light

• Automatically illuminates when you open the door

No-frost operation

• Frost-free freezer section and automatic defrost refrigerator offer low maintenance operation

Open door alarm

• Audible alarm will sound if the refrigerator door is left ajar for over one minute

High temperature alarm

• Audible alarm will sound if the temperature in the refrigerator or freezer compartment is too high

Power failure alarm

• If the temperature exceeds acceptable levels due to power failure, an audible alarm will sound

LED visual alarms

• All alarms are both audible and visual, with lamps in the control panel that will illuminate when the alarm is sounded

Intensive cooling & freezing function

• Allows you to rapidly cool the refrigerator or freezer section, ideal for bringing newly loaded groceries to a safer storage temperature

Child lock

• Temperature controls include a locking function to prevent accidental setting changes

Factory reversible door swing

• Unit ships RHD unless ordered reversed in our factory. The doors are not user-reversible

Fully finished platinum cabinet

• Allows the unit to be used freestanding

100% CFC free

• Environmentally friendly design without ozone-damaging chemicals

Exterior

PNLRH Stainless steel panel installed on right side to cover FFBF181ES cabinet : PNLLH Stainless steel panel installed on left side to cover FFBF181ES cabinet

Overview

Height of Cabinet : 78.75" (200 cm)

Height to Hinge Cap : 79.25" (201 cm)

Width : 23.63" (60 cm)

Width with Door Open : 24.63" (63 cm)

Depth : 25.25" (64 cm)

Depth with Handle : 27.25" (69 cm)

Depth with door at 90° : 47.0" (119 cm)

Capacity : 12.8 cu.ft. (362 L)

Defrost Type : Frost-Free/Automatic

Door : Stainless Steel

Cabinet : Platinum

US Electrical Safety : ETL

Canadian Electrical Safety : ETL-C

Energy Usage/Year : 474.0kWh/year

Amps : 1.5

Voltage/Frequency : 115 V AC/60 Hz

Weight : 185.0 lbs. (84 kg)

Shipping Weight : 210.0 lbs. (95 kg)

Parts & Labor Warranty : 1 Year

Compressor Warranty : 5 Years

Refrigerator-Freezer

Door Swing : RHD

Reversible : Factory Reversible

Adjustable Shelves : Yes

Interior Drawers : Yes

Drawer Qty : 5

Crisper Qty : 2

Crisper Finish : Transparent

Crisper Cover : Glass

Wine Bottle Shelving : Yes

Interior Light : Yes

Refrigerator - Interior Height : 44.0" (112 cm)

Refrigerator - Interior Width : 19.25" (49 cm)

Refrigerator - Interior Depth : 17.5" (44 cm)

Refrigerator - Capacity : 9.35 cu.ft

Refrigerator - Shelf Type : Glass and Scalloped

Refrigerator - Shelf Qty : 4

Refrigerator - Full Door Shelves : 4

Refrigerator - Temperature Range : 34º to 46ºF

Freezer - Interior Height : 24.0" (61 cm)

Freezer - Interior Width : 16.5" (42 cm)

Freezer - Interior Depth : 13.0" (33 cm)

Freezer - Capacity : 3.46 cu.ft

Thermostat Type : Digital

Fan Type : Interior and Exterior

Refrigerant Type : R134a

Refrigerant Amount : 5.11 oz.

High Side PSI : 215.0

Low Side PSI : 36.0

Level Legs : 2

Freezer - Temperature Range : -6º to 6ºF

Compressor Step Height : 8.0" (20 cm)

Compressor Step Width : 16.5" (42 cm)

Compressor Step Depth : 5.0" (13 cm)
