ADA compliant design

• 32 1/4" height allows installation under lower ADA compliant counters

No pump or drain required

• Convenient design allows more flexibility in positioning the unit

Built-in capable

• Make the best use of space by installing your icemaker under the counter and flush with other cabinets

Complete stainless steel exterior

• Door, cabinet, and kickplate feature full 304 grade stainless steel construction made in the USA

Professional handle

• Sleek handle in brushed stainless steel is horizontally mounted for a modern look

Mid-sized capacity

• Produces and stores up to 12 pounds of ice per day cycle

Removable bin

• Bucket can removed for fast and easy cleaning

Insulated storage bin

• Ice stays solid longer in this cold-protected bin

Storage compartment

• Includes lower compartment for storing non-refrigerated items

Reversible door

• User-reversible design allows you to change the door swing to better accommodate your setup

Right angle plug

• Design allows you to plug the unit in flush against the wall socket with no need to add extra depth

Manual defrost

• Static cooling system helps to keep ice frozen for longer periods of time compared to other systems

Ice scoop included

• Large plastic ice scoop included for your convenience

Sealed back

• Flush design with no exposed coils for easier cleanup

Defrost drain included

• Rear-mounted drain for easier cleaning

Fully finished cabinet

• Allows the icemaker to be used freestanding

100% CFC free

• Environmentally friendly design without ozone-damaging chemicals

Exterior

LHD Door reversal to left hand swing : Latch Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.

Icemaker

Door Swing : RHD

Reversible : Yes

Daily Ice Production : 12.0 lbs. (5 kg)

Ice Storage Capacity : 12.0 lbs. (5 kg)

Ice Shape : Crescent

Number of Ice Cube Sizes : 1

Refrigerant Type : R134a

Refrigerant Amount : 2.12 oz.

High Side PSI : 250.0

Low Side PSI : 110.0

Interior Height : 11.5" (29 cm)

Interior Width : 10.0" (25 cm)

Interior Depth : 12.63" (32 cm)

Level Legs : 4

Overview

Height of Cabinet : 32.0" (81 cm)

Height to Hinge Cap : 32.25" (82 cm)

Width : 15.18" (39 cm)

Depth : 21.0" (53 cm)

Depth with Handle : 22.25" (57 cm)

Depth with door at 90° : 34.0" (86 cm)

Capacity : 1.0 cu.ft. (28 L)

Defrost Type : Manual

Door : Stainless Steel

Cabinet : Stainless Steel

US Electrical Safety : UL

Canadian Electrical Safety : ULC

Amps : 1.7

Voltage/Frequency : 115 V AC/60 Hz

Weight : 100.0 lbs. (45 kg)

Shipping Weight : 110.0 lbs. (50 kg)

Parts & Labor Warranty : 1 Year

Compressor Warranty : 5 Years
