DIMENSIONS & WEIGHT

Product : 29-3/4"(W) x 52-1/16"(H) x 24-3/8"(D)

Cut-out : 28- 1/2"(W) x 51-15/16"(H) x 23-1/2"(D)

Packing : 33"(W) x 30"(D) x 57"(H)

Net weight (Kg) : Approx. 122.6 kg (270lbs)

Gross weight(Kg) : Approx. 137.6 kg (303bs)

LIMITED WARRANTY

LIMITED WARRANTY : 1 Year Parts & Labor

LOWER OVEN

Capacity (cu.ft) : 4.70

Interior Color : Blue

Cleaning : EasyClean® / Self-Clean (3,4,5 hours)

Variable cleaning time : Yes (3,4,5 hrs)

Variable broil : Yes( Full,Center / High,Med,Low)

Broil element : 2,500 watts inner / 1,500 watts outer

Broil element pass : 8

Bake element : 2,500 watts

Bake element type : Hidden (8 pass)

# of rack position : 5

12 hrs. shut-off : Yes

- # of light : 3 (Halogen Lamp - 3 dimension lighting)

Convection conversion : Yes

-Convection element : Yes (2,000 watts Sheath heater)

Proof : Yes

Variable warm : Yes (High,Med,Low)

Color & Material : STS Finish(Al) / Black Stainless

POWER/RATINGS

Rating : 7.8 KW

Electrical Supply : 120/240 VAC,120/208 VAC

Max. Amp Load : 32.5 A

UPC CODES

LWD3063BD Black Stainless Steel : 048232336504

UPPER OVEN

Capacity (cu.ft) : 4.7

Interior Color : Blue

Cleaning : EasyClean® / Self-Clean (3,4,5 hours)

Variable cleaning time : Yes (3,4,5 hrs)

Variable broil : Yes( Full,Center / High,Med,Low)

Broil element : 2,500 watts inner / 1,500 watts outer

Broil element pass : 8

Bake element : 2,500 watts

Bake element type : Hidden (8 pass)

# of rack position : 5

12 hrs. shut-off : Yes

- # of light : 3 (Halogen Lamp - 3 dimension lighting)

Convection conversion : Yes

-Convection element : Yes (2,000 watts Sheath heater)

Proof : Yes

Meat probe : -

Variable warm : Yes (High,Med,Low)

Favorites menu : 3 (1. Bread,2. Meat,3. Chicken)

# of My menu : -

Gourmet recipe bank (e-cookbook) : -

Specialized cooking : -
