• 6.9 cu.ft. Large Capacity

• ProBake Convection®

• EasyClean®

• SmoothTouch™ Glass Controls

• ThinQ® Technology with ThinQ Care

APPEARANCE

Knobs : Aluminum

Handle/Knobs : Matte Black Stainless Steel, Black Stainless Steel, Stainless Steel

PrintProof™ Finish : Yes (only LTG4715BM & LTG4715BD)

All Available Colors : Matte Black Stainless Steel, Black Stainless Steel, Stainless Steel

Oven Door Feature : WideView™ Window

CAPACITY

Total Oven Capacity (cu. ft.) : : 6.9

Upper Oven Capacity (cu. ft.) : 2.6

Lower Oven Capacity (cu. ft.) : 4.3

CONTROLS

Display : VFD

Language : English

Cooktop Control Type : Front Tilt-Control Knobs

Oven Control Type : Glass Touch (SmoothTouch™) and Control Knob

Clock : Yes

Temperature Unit of Measure : Fahrenheit / Celsius

COOKTOP

Cooktop Finish : : Stainless Steel

Center (Warming Zone) : : 2300

Center (Warming Zone) (BTU) : : 10000 / 10000 (Oval)

Burner/BTU - Left Rear : 9100 / 9100

Burner/BTU - Right Rear : 5000 / 5000

Burner/BTU - Left Front : 12,000/10,000

Burner/BTU - Right Front : 18500 / 12500 (UltraHeat™)

Burner Simmer / BTU - Left Rear : 1,100

Burner Simmer / BTU - Right Rear : 650

Burner Simmer / BTU - Left Front : 1,200

Burner Simmer / BTU - Right Front : 1,330

DIMENSIONS/CLEARANCES/WEIGHT

Shipping Weight (lbs) : 280

Weight (Product) : 225

Cabinet Width (in) : 30"

Overall Height (in) - including backguard : 37 7/8"

Height to Cooking Surface (in) : 36"

Overall Width (in) : 29 7/8"

Oven Interior Dimensions (Upper) (in) (W x H x D) : 24 13/16" x 9 1/4" x 20"

Oven Interior Dimensions (Lower) (in) (W x H x D) : 24 13/16" x 14 1/4" x 20"

Carton Dimensions (in) (W x H x D) : 31 31/32" x 51" x 30 17/32"

Overall Depth (in) - including handle : 28 15/16"

LOWER OVEN FEATURES

Convection Burner (BTU/h) : 14,000 / 12,000 (LNG/LPG)

Convection Conversion : : Yes

Convection System/Mode/Cooking System : : ProBake Convection®

Oven Cooking Modes : : Bake, Convection Bake, Convection Roast, Warm, Proof, EasyClean, SelfClean, Remote Start

Oven Control Features : : Glass Touch (SmoothTouch™)

EasyClean® : : Yes

Self Clean : : Yes

GoCook Smart Oven Light : : Yes (1)

No. of Rack Positions : 4

Door Lock : : Yes

Automatic Safety Shut-Off : : After 12 hours

MATERIALS/FINSHES :

Oven Door Feature : WideView™ Window

POWER/RATINGS

Amp at 120V : 8.5A

kW at 120V : 996W

Requirements : 120 VAC

SUMMARY

ProBake Convection® : : Yes

Slide-In : : Yes

Fuel Type : Gas

Double Oven : : Yes

Self + EasyClean® : Yes

ThinQ Care : : Yes

THINQ® SMART FEATURES

Wi-Fi Enabled : : Yes

SmartDiagnosis™ : Yes

ThinQ Care : Yes

UPPER OVEN FEATURES

Broil Element (BTU) : 14,500 / 12,500 (LNG/LPG)

Bake Element (BTU) : 14,500 / 12,500 (LNG/LPG)

Oven Cooking : : Conventional

Oven Cooking Modes : : Bake, Broil, Pizza, EasyClean, SelfClean, Remote Start

Oven Control Features : : Glass Touch (SmoothTouch™)

EasyClean® : : Yes

Self CleanUpper Oven : : Yes

GoCook Smart Oven Light : : Yes (1 Light)

No. of Rack Positions : 2

Door Lock : : Yes

Automatic Safety Shut-Off : : After 12 hours

WARRANTY/UPC

UPC : 048231339742

Parts & Labor : 1 Year

• Use and Care Manual

• Specifications
