• 30 cu. ft. Capacity

• Door-in-Door® with adjustable bin

• CoolGuard™

• Tall Ice & Water Dispenser® with Measured Fill

• Dual Ice Maker

• ThinQ® Technology

CAPACITY

Refrigerator (cu.ft.) : 19.30

Freezer (cu.ft.) : 10.40

Total Capacity (cu.ft.) : 29.70

CONVENIENCE

Display Type : Smooth Touch Control / White LED

Temperature Controls : Electronic/Digital

Door Alarm : Yes

Child Lock : Yes

Auto Closing Door Hinge : Yes

ADA Compliant : Yes

Sabbath Mode : Yes

LoDecibel™ Quiet Operation : Yes

COOLING

Linear Compressor : Yes

Smart Cooling Plus™ System : Yes

Door Cooling+ : Yes

Multi-Air Flow™ System : Yes

Temperature Sensors : 9

Fresh Air Filter : Yes

Evaporator : 2

DIMENSIONS/CLEARANCES/WEIGHTS

Depth with Handles : 36 5/8"

Depth without Handles : 34 1/8"

Depth without Door : 29 7/8"

Depth (Total with Door Open) : 48 1/2"

Height to Top of Case : 68 7/8"

Height to Top of Door Hinge : 70 1/4"

Width : 35 3/4"

Width (Door Open 90° with Handle) : 44 1/4"

Width (Door Open 90° without Handle) : 40"

Door Edge Clearance with Handle : 4 1/4"

Door Edge Clearance without Handle : 2 1/8"

Installation Clearance : Sides 1/8", Top 1", Back 2"

Weight (Unit/Carton) : 331 lbs. / 364 lbs.

Carton Dimensions (WxHxD) : 38" x 73" x 39"

ENERGY

Energy Consumption (kWh/Year) : 730

ENERGY STAR® Qualified : Yes

FREEZER

Door Type : Pull Drawer

Drawers : 3-Tier Organization

DuraBase™ Solid Drawer Base : Yes

Drawer Divider : Yes

Ice Bin / In-Door Ice : Icemaker & Ice bin in the freezer

Freezer Light : Premium LED

Freezer Handle : SmartPull™ Handle

LIMITED WARRANTY

Parts & Labor : 1 Year

Sealed System (Parts & Labor) : 5 Years

Compressor (Parts & Labor) : 5 Years

Linear Compressor (Parts Only) : 6-10 Years

MATERIALS AND FINISHES

Contour Door : Yes

Hidden Hinges : Yes

Surface : Smooth

Fingerprint & Smudge Resistant Exterior : Yes

Handles : Matching Commercial Handles

All Available Colors : PrintProof™ Stainless Steel, PrintProof™ Black Stainless Steel

REFRIGERATOR

No. of Shelves : 4 Split(3 Fixed+1Folding)

Folding Shelf : 1

Cantilevered Shelves : Yes

Shelf Construction : Spill Protector™ Tempered Glass

Crisper Bins : 2 Humidity Crispers

Glide N’ Serve™ Drawer : Yes

Temperature Control Pantry : Digital Control

Flat Metal Back Wall : Yes

Refrigerator Light : Micro Surface LED

REFRIGERATOR DOOR

Door-In-Door® with ColdSaver™ Panel : Yes

Adjustable Door-in-Door® Bins : Yes

No. of Bins : 10

Door Bin Construction : 1 Piece (clear)

SUMMARY

Door Type : French 3-Door

ThinQ® : Yes

wi-fi Enabled : Yes

Total Capacity (cu.ft.) : 29.70

Ice & Water Dispenser : Yes

ENERGY STAR® Qualified : Yes

Standard Depth : Yes

SmartDiagnosis™ : Yes

Sabbath Mode : Yes

Door Cooling+ : Yes

THINQ® SMART FEATURES

Wi-Fi Enabled : Yes

ThinQ® : Yes

Works with : Google Assistant, Amazon Alexa

SmartDiagnosis™ : Yes

WARRANTY & UPC

UPC : 048231803328

WATER & ICE SYSTEM

Ice & Water Dispenser : Yes

Dispenser Type : Integrated Ice & Water Dispenser

Measure Fill : Yes

Daily Ice Production (lbs) : 5.5 lbs

IcePlus™ Production (lbs) : 5.9 lbs

Ice Storage Capacity (lbs) : 3.0 lbs + 2.5 lbs

Ice System : Slim SpacePlus®

Dual Ice : Yes

Dispenser Light : Yes

Water Filter : LT1000P
