16,000 BTU Burner

• for boiling, searing, and stir-frying.

OptiSim® Burner

• the wide & thick burner design diffuses heat evenly and reduces hot spots -- perfect for simmering delicate sauces or melting chocolate.

Electronic Re-Ignition

• automatically re-ignites the burner in case the flame goes out.

Easy-to-Clean

• a one-piece stainless steel design makes clean-up easy.

Continuous Cast Iron Grates

• makes it easy to slide pots & pans from burner to burner.

• Bosch gas cooktops are engineered to perform precisely, offering high heat and low simmer options for optimal cooking flexibility.

General

Product group : Hob

Brand : Bosch

Product name / series name : gas hob w integrated controls

Product series : 500 Series

SKU : NGM5656UC

Internal article number : NGM5656UC

EAN code : 4242005036493

Construction type : Built-in

Type of control : Mechanical

Type of control : Front, sword knobs

Energy input : Gas

Total number of cooktop burners : 5

Number of gas burners : 5

Number of electric cooking zones : 0

Number of electric elements : 0

Number of radiant elements : 0

Number of halogen elements : 0

Number of induction elements : 0

Number of electric warming zones : 0

Location of control panel : Front

Gas type : Natural gas 15 mbar (USA)

Alternative gas type : Liquid gas 27,5 mbar (USA)

Basic surface material : Stainless Steel

Color of frame : Stainless Steel

Gas connection rating (W) : 15100

Current (A) : 15

Watts (W) : 360

Volts (V) : 120

Frequency (Hz) : 60

Power cord length (cm) : 152.4

Plug type : 120V-3 prong

Location of gas connection : Bottom, Rear, Right

Height of the packed product (mm) : 203

Width of the packed product (mm) : 635

Depth of the packed product (mm) : 1092

Minimum height for installation (mm) : 486

Maximum height for installation (mm) : 486

Minimum width for installation (mm) : 887

Maximum width for installation (mm) : 887

Depth for installation (mm) : 97

Net weight (kg) : 19.1

Gross weight (kg) : 23.1

Automatic programmes : Yes

Location of the heating element : front left

Location of 2nd heating element : center left

Location of 3rd heating element : back left

Location of 4th heating element : middle back

Location of 5th heating element : back right

Location of 6th heating element : center right

Type of heating element : Gas

Type of 3rd heating element : Gas

Type of 5th heating element : Gas

Power of the heating element : 2.93

Power of 3rd heating element (kW) : 2.93

Power of 5th heating element (kW) : 1.61

Power on indicator : No

Plate on indicator : 0

Type of regulation : Step energy regulated

Type of lid : Without

Ignition system : Yes

Residual heat indicator : Without

Main on/off switch : No

Safety device : Without Safety

Timer : No

Included accessories : 1 x nozzle set for liquid gas, 1 x cast iron pan support

Optional accessories : HEZ27751, HEZ298102

Time-setting options : No delay options

What type of hob is it? : Gas

Prevent boiling over with cooking sensor : No

Flexible induction technology supported : No

Hob with booster function : No

Temperature control for perfect frying results : No

Cord included : Yes

Wok burner supported : No

• Product data sheet

• Installation Instruction

• Installation Instruction

• Installation Instruction

• User Manual

• User Manual
